IEC Magnetic Contactor, No Auxiliary Contacts, 480V AC, 4 P, Non-Reversing, Screw MPN:XTCF160G00C
Free Shipping
In Stock
The Eaton XT IEC Magnetic Contactor is a reliable and efficient solution for industrial power circuit applications. Designed for non-reversing operation, this four-pole contactor features a 480V AC coil and 160A amperage rating, making it suitable for a wide range of industrial uses. Its compact size and DIN Rail/Panel mounting options provide flexibility in installation. The contactor's integrated surge suppression component and IP20 rating ensure reliable performance in harsh environments. Ideal for use in control circuits, motor control, and other industrial applications, the XT contactor offers a durable and long-lasting solution with a 10,000,000 cycle mechanical durability rating.
Top product features:
- Has four poles for handling multiple electrical circuits
- Operates as a non-reversing contactor within its specified functions
- Has a 480V AC coil voltage for high-voltage applications
Top product applications:
- Motor Control in Industrial Power Circuits
- High-Reliability Power Distribution in Manufacturing Facilities
- Control of Electric Motors in Heavy Industry
The Eaton XT IEC contactor is an IEC magnetic contactor with four poles and a 480V AC coil. It is designed to operate as a non-reversing contactor within its specified functions and is supplied without auxiliary contacts, belonging to the XT series with Frame G size, rated for operation within specified industrial power circuit parameters.
- Poles: 4
- - Action: Designed to operate as a non-reversing contactor within its specified functions
- - Coil voltage: 480V AC
- - Amperage rating: 160A
- - Auxiliary contacts: No Auxiliary Contacts
- - Frame size/Series: Frame G
- XT
- - Mounting: DIN Rail, Panel
- - Electrical connection: Screw terminals
- - Embedded surge suppressor: Includes an integrated surge suppression component (if applicable)
- - Enclosure: No Enclosure
- - IP rating: IP20
- - Maximum voltage rating: Rated for operation up to 690V AC within specified conditions
- - Frequency: 50/60 Hz
- - Certifications: CE Marked
- CSA Certified
- EN 60947
- IEC 60947
- UL Listed
- RoHS
- - Mechanical durability: 10,000,000 cycles
- - Dimensions: Height 6.7 in, Width 6.42 in, Depth 5.03 in
- - Operating temperature range: -13°F to 122°F
Additional Information
- Country of Origin: DE
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 12 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 7.10
- Package Width: 5.50
- Package Height: 7.60
- Package Weight: 6.45
