IEC Magnetic Contactor, 1NC, 208V AC, 3 P, Non-Reversing, Screw MPN:XTCE009B01E

• Eaton XT IEC contactor is an IEC magnetic contactor (3-pole, non-reversing) with a 208 V AC coil and a 9 A amperage rating. It includes one auxiliary contact (1NC) and has a frame size B within the XT series. Suitable for DIN Rail or Panel mounting as specified and rated for operation within the specified voltage range up to 690 V AC, with an IP20 enclosure rating and screw terminals.

  - Action: Non-Reversing

• - Reversing: No
• - Poles: 3
• - Coil voltage: 208 V AC
• - Amperage rating: 9 A
• - Full Load Amps - Inductive/Resistive: 9 A / 22 A
• - Auxiliary contacts: 1 NC
• - Contact configuration: 1 NC
• - Frame/Series: Frame B
• XT
• - Mounting: DIN Rail, Panel
• - Connection type: Screw
• - Enclosure: No Enclosure
• - IP rating: IP20
• - Maximum voltage rating: 690 V AC
• - Certifications: UL Listed
• CSA Certified
• - Frequency: 60 Hz
• - Mechanical durability: 10,000,000 cycles
• - Embedded surge suppressor: Yes
• - Item: IEC Magnetic Contactor
• - Type: Full voltage non-reversing contactor
• - Width x Height x Depth: 3 in x 2 in x 2.95 in
