IEC Magnetic Contactor, 1NC, 24V DC, 3 P, Non-Reversing, Screw MPN:XTCE007B01TD

• The Eaton XT IEC contactor is a 3-pole, non-reversing IEC magnetic contactor with a 24 V DC coil. It is rated for operation at the specified current levels and includes one NC auxiliary contact. The device uses screw terminals and supports DIN Rail or Panel mounting in frame size B (XT series). It carries UL Listed and CSA Certified marks and is designed for use within the specified voltage and frequency ranges, with IP20 protection and no enclosure.

  Key features:

  • - Poles: 3
  • Main contact configuration: 1 NC
  • Auxiliary contacts: 1 NC (Includes 1NC)
  • - Coil voltage: 24 V DC
  • - Electrical ratings: 7 A inductive, 22 A resistive (Full Load)
  • - Durability: 10,000,000 electrical cycles
  • 10,000,000 mechanical cycles
  • - Termination: Screw terminals
  • - Mounting: DIN Rail, Panel
  • - Frame/Series: XT series
  • Frame size B
  • - Maximum voltage: 690 V AC
  • Frequency: 50/60 Hz
  • - Enclosure/IP: IP20
  • No Enclosure
  • - Certifications: UL Listed
  • CSA Certified
  • - Temperature range: -13°F to 122°F
  • - Dimensions: 2.95 in depth
  • 3.00 in height
  • 1.77 in width
  • - Reversing: No (Non-Reversing)
