IEC Magnetic Contactor, No Auxiliary Contacts, 480V AC, 4 P, Non-Reversing, Screw MPN:XTCF200G00C
Free Shipping
In Stock
The Eaton XT IEC contactor is a reliable and efficient solution for a wide range of industrial applications. Designed for use in 480V AC environments, this contactor is ideal for controlling high-amperage loads in settings such as manufacturing, oil and gas, and power generation. With its non-reversing action and high mechanical durability, the XT IEC contactor provides consistent and reliable performance, even in demanding conditions. Its compact design and DIN rail mounting make it easy to integrate into existing systems, making it a versatile and practical choice for applications requiring high power control.
Top product features:
- The Eaton XT IEC contactor is designed for high mechanical durability under normal conditions.
- It is rated for operation with the specified voltage and current ratings.
- It is manufactured in accordance with recognized compliance requirements.
Top product applications:
- Control Panel Equipment
- Industrial Automation Systems
- Power Distribution Systems
The Eaton XT IEC contactor is an IEC magnetic contactor rated for operation with the specified voltage and current ratings.
- Number of Poles: 4
- - Action: Non-Reversing
- - Reversing: No
- - Amperage Rating: 200A
- - Coil Voltage: 480V AC
- - Auxiliary Contacts: No Auxiliary Contacts
- - Contact Configuration: 0 NO, 0 NC
- - Mounting Style: DIN Rail, Panel
- - Electrical Connection: Screw
- - Frame Size / Series: Frame G / XT
- - Maximum Voltage Rating: Rated for use at voltages up to 690V AC within applicable standards
- - IP Rating: IP20
- - Enclosure: No Enclosure
- - Certifications: Complies with relevant industry standards and certifications
- - Standards: Manufactured in accordance with recognized compliance requirements
- - Dimensions: Width 6.42 in
- Height 6.7 in
- Depth 5.03 in
- - Mounting Details: Mounting Hole Diameter 0.24 in
- Hole Distance (Height) 6.14 in
- Hole Distance (Width) 2.76 in
- - Maximum Operating Temperature: 122 Degrees F
- - Minimum Operating Temperature: -13 Degrees F
- - Mechanical Durability: Designed for high mechanical durability under normal conditions
- - Product Name: Eaton XT IEC contactor
