IEC Magnetic Contactor, 1NO, 24V DC, 3 P, Non-Reversing, Screw MPN:XTCE032C10TD
Free Shipping
In Stock
The Eaton XT IEC Magnetic Contactor is a reliable and efficient solution for controlling electrical circuits in various industrial and commercial applications. With its 3-pole, non-reversing design and 24V DC coil, this contactor is ideal for use in control panels, machines, and equipment that require precise and consistent switching. Its high current capacity and fast response time make it suitable for applications involving motors, pumps, and other high-power devices. The contactor's compact size and DIN rail or panel mounting options make it easy to integrate into existing systems, providing a reliable and efficient way to control electrical circuits.
Top product features:
- The Eaton XT IEC contactor has three poles.
- The contactor has one normally open auxiliary contact.
- The contactor has a surge suppressor embedded within it.
Top product applications:
- General Purpose Control
- Industrial Control Systems
- Machine Automation
The Eaton XT IEC contactor is a 3-pole, non-reversing IEC magnetic contactor with a 24V DC coil and one normally open auxiliary contact (1NO). It follows IEC standards (Frame Size C) and is rated for operation within specified power circuit parameters. The unit uses screw terminals and supports DIN rail or panel mounting. It has a rated current capacity of 32A (inductive) and 45A (resistive) under specified conditions, with operation at 50/60 Hz. It is rated for operation up to 690V AC within the specified voltage range. Certifications conform to applicable standards including UL Listed, CSA Certified, CE Marked, EN 60947, IEC 60947, and RoHS
- includes an embedded surge suppressor.
Key features
- - Poles: 3
- - Coil: 24 V DC
- Coil voltage: 24 V DC
- - Auxiliary contacts: 1 NO
- - Mounting: DIN Rail, Panel
- - Terminals: Screw
- - Frame/Series: Frame C
- Series XT
- - Enclosure: No Enclosure
- IP20
- - Certifications/Compliances: UL Listed
- CSA Certified
- CE Marked
- EN 60947
- IEC 60947
- RoHS
- - Full-load currents: 32 A (inductive)
- 45 A (resistive)
- - Electrical durability: 300 (AC-4 400V Ie)
- 800 (AC-1 400V Ie)
- 800 (AC-3 400V Ie)
- - Mechanical durability: 10,000,000 cycles
- - Reversing: No
- - Maximum voltage: 690V AC
- - Response time: as specified (AC Opening <14 ms
- AC Closing <22 ms
- DC Opening <30 ms
- DC Opening <47 ms)
Additional Information
- Country of Origin: RO
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 3.50
- Package Width: 1.90
- Package Height: 4.00
- Package Weight: 1.21
