Circuit Breaker, PDG Series, 25A, 2 Pole, 600V AC, 25kA at 480V AC, A Curve MPN:PDG22F0025TFFL
Discount: See in Cart
Free Shipping
In Stock
Free Shipping
In Stock
SKU
510-G100901853
Circuit Breaker, PDG Series, 25A, 2 Pole, 600V AC, 25kA at 480V AC, A Curve
Protect your electrical system with the Eaton PDG Series Circuit Breaker, a reliable and efficient solution for 2-pole applications. This 25A, 600V AC circuit breaker is designed for use in a variety of settings, including commercial and industrial facilities, and is ideal for applications where high currents are present. With a maximum short-circuit current rating of 25kA at 480V AC, this breaker provides robust protection against electrical faults. Its thermal-magnetic trip mechanism ensures fast and accurate detection of overloads and short circuits, making it an essential component for ensuring the safety and reliability of your electrical system.
Top product features:
- Two-pole design for phase three connections
- Thermal magnetic trip type for fast and reliable overload protection
- Instantaneous trip feature for immediate shutdown in case of short circuits
Top product applications:
- Industrial Control Panels
- Commercial Electrical Distribution Systems
- Manufacturing Equipment
Circuit Breaker, 25 A Amps, AC Voltage Rating 600V AC, Max. AIR Rating 25 kA at 480V AC, Circuit Breaker Type Standard, Number of Poles 2, DC Voltage Rating Not Rated, Terminal Connection Standard Terminals Load Only, Trip Type Thermal Magnetic, Phase Three, Instantaneous Trip Fixed, Phase Connection AB, Frame Size 225A/Frame 2, Height 6 in, Width 4.11 in, Depth 3.5 in, Min. Wire Size 14 AWG, Max. Wire Size 1/0 AWG, Max. Operating Temp. 158 Degrees F, Min. Operating Temp. -4 Degrees F
Additional Information
- Country of Origin: DO
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 10 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 9.00
- Package Width: 6.00
- Package Height: 4.00
- Package Weight: 5.00
Product info last updated on February 14, 2026 3:35pm UTC
Category: Circuit Protection
