IEC Magnetic Contactor, No Auxiliary Contacts, 24V DC, 4 P, Non-Reversing, Screw MPN:XTCF200G00TD
Free Shipping
In Stock
The Eaton XT IEC contactor is a reliable and efficient solution for controlling 24V DC-powered electrical circuits. Suitable for a wide range of applications, including industrial automation, HVAC systems, and renewable energy installations, this non-reversing contactor provides safe and reliable switching for resistive loads up to 200A. Its compact design and easy mounting options make it ideal for space-constrained applications. With its robust construction and high-quality components, the Eaton XT IEC contactor ensures reliable operation in harsh environments, meeting the demands of modern industrial and commercial settings. Perfect for use in control panels, machines, and equipment.
Top product features:
- Operates within specified voltage and current ranges as per IEC standards.
- Rated for resistive loads up to 200 A within specified conditions.
- Includes an integrated surge suppression component to protect against electrical surges.
Top product applications:
- Industrial Control Systems
- Automotive Electrical Systems
- Power Distribution Systems
The Eaton XT IEC contactor is an IEC magnetic contactor with a 24 V DC coil, 4 poles, and no auxiliary contacts. It is rated for operation within the specified voltage and current ranges as per IEC standards. Compatible with standard mounting configurations. Configured as a non-reversing contactor according to its specifications.
- Product name: Eaton XT IEC contactor
- - Action: Non-Reversing
- - Reversing: No
- - Coil voltage: 24 V DC
- - Poles: 4
- - Contact configuration: 0 NO, 0 NC
- - Full Load Amps (Resistive): rated for resistive loads up to 200 A within specified conditions
- - Maximum voltage rating: rated for operation at voltages up to 690 V AC within specified parameters
- - Embedded surge suppressor: includes an integrated surge suppression component (if applicable)
- - Terminals: Screw
- - Mounting style: DIN Rail, Panel
- - Frame size: G
- - Enclosure: No Enclosure
- - IP rating: IP20
- - Certifications: UL Listed
- CSA Certified
- EN 60947
- IEC 60947
- CE Marked
- RoHS
- - Dimensions (HxWxD): 6.69 in × 5.24 in × 6.89 in
- - Operating temperature: -13 °F to 122 °F
Additional Information
- Country of Origin: RO
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 47 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 7.20
- Package Width: 7.30
- Package Height: 5.30
- Package Weight: 6.42
