IEC Magnetic Contactor, 1NO, 24V AC, 4 P, Non-Reversing, Screw MPN:XTCF032C10T

• The EATON - IEC Magnetic Contactor is a non-reversing, 4-pole contactor with a coil voltage of 24V AC. It's rated for operation within the specified amperage range up to 32A and has a continuous ampere rating of the same value. The product operates at frequencies between 50-60 Hz and is compatible with full load currents of both inductive (18 A) and resistive (45 A) types. This contactor features screw terminals intended for secure wiring installation.

  Key Features:

• - Auxiliary Contact Configuration: Comes with one normally open (1NO) auxiliary contact.
• - Certifications & Compliances: Certified by EN 60947, CSA, UL Listed
• IEC 60947 standards and carries a CE Marking. Compliance with these certifications does not guarantee safety.
• - Horsepower Ratings: Designed for compatibility with horsepower ratings ranging from 7.5 hp (@ Single Phase -240V AC/ @ Three Phase -208V AC/ @ Three Phase -240V AC),10 hp (@ Three Phase -480V AC), up to15 hp (@ Three Phase -600V AC).
• - Operating Temperature Range: Operates within the temperature range of -13 Degrees F to122 Degrees F.
• - Mounting Style: Versatile mounting options include DIN Rail or Panel mounting.
• - Response Time: Response times may vary based on operation type – DC Operated Opening Delay (30 msec), DC Operated Closing Delay (47 msec), AC Operated Closing Delay (6 to22 msec), and AC Operated Opening Delay(8to14 msec).
