IEC Magnetic Contactor, No Auxiliary Contacts, 240V AC, 4 P, Non-Reversing, Screw MPN:XTCF080D00B
Free Shipping
In Stock
The Eaton IEC Magnetic Contactor is a reliable and efficient solution for industrial applications, offering a non-reversing, four-pole design with a 240V AC coil voltage. Suitable for use in a variety of settings, including DIN Rail and panel mounting, this contactor provides secure electrical connections through screw-type terminals. With a high level of mechanical operating durability and a maximum voltage rating of up to 690V AC, it can handle demanding power supply systems. Ideal for applications such as motor control, this contactor is designed to provide reliable and efficient operation in a range of industrial settings.
Top product features:
- Non-reversing action with response times varying between 8-54 msec depending on operation type.
- Horsepower compatibility ranges from 15 hp at single phase -230V/240V or three-phase -208V up to 50 hp at three-phase -575V.
- Mechanical Operating Durability tested up to ten million cycles.
Top product applications:
- Industrial control systems
- Motor control and power distribution
- Automated manufacturing and assembly lines
The EATON - IEC Magnetic Contactor is a non-reversing, four-pole contactor suitable for use in industrial applications. It operates with a coil voltage of 240V AC and has no auxiliary contacts. The contactor is part of the XT series and adheres to CE, CSA, EN/IEC 60947, RoHS, and UL Listed standards. Its frame size D design allows it to handle inductive full load currents up to 50 A and resistive full load currents up to 80 A. With an IP20 rating, this unit operates within a temperature range of -13 Degrees F to 122 Degrees F.
Key features include:
- - Non-reversing action with response times varying between 8-54 msec depending on operation type.
- - Horsepower compatibility ranges from 15 hp at single phase -230V/240V or three-phase -208V up to 50 hp at three-phase -575V.
- - Suitable for DIN Rail or Panel mounting style with overall dimensions being: depth –5.79 in
- height –4.53 in
- width –3.35 in.
- - Mechanical Operating Durability tested up to ten million cycles.
- - Maximum Voltage Rating is up-to 690 V AC, compatible with various power supply systems.
- - Terminal Connection Type: Screw type terminals for secure electrical connections.
Please note that this product does not include any enclosure (NEMA Enclosure Rating: No Enclosure) nor auxiliary contacts (Number of Auxiliary Contacts:0).
Additional Information
- Country of Origin: RO
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 6.00
- Package Width: 4.90
- Package Height: 4.00
- Package Weight: 2.45
