IEC Magnetic Contactor, 1NO, 480V AC, 4 P, Non-Reversing, Screw MPN:XTCF045C10C
Free Shipping
In Stock
The Eaton XT IEC Magnetic Contactor is a reliable and efficient switching device designed for a wide range of applications. Suitable for use in industrial control systems, the 4-pole, non-reversing contactor features a 480V AC coil and 1 normally open auxiliary contact. It is easy to install and maintain, with screw terminals for wiring and a compact design for mounting on DIN rails or panels. The contactor's high durability and long lifespan make it an ideal choice for applications in harsh environments, including manufacturing, oil and gas, and renewable energy. Its certifications and standards compliance ensure safe and reliable operation.
Top product features:
- The Eaton XT IEC contactor features a 4-pole, non-reversing, electrically operated switching device.
- It has 1 normally open auxiliary contact for additional control functionality.
- The contactor uses screw terminals for convenient and secure wiring connections.
Top product applications:
- Automotive Applications
- Industrial Automation and Control Systems
- Power Generation and Distribution Systems
The Eaton XT IEC contactor is a 4-pole, non-reversing, electrically operated switching device (IEC Magnetic Contactor) with a 480V AC coil. It features 1 normally open auxiliary contact (1NO) and uses screw terminals for wiring. This XT-series frame C unit is suitable for mounting on DIN rails or panels, with an electrical rating up to 690V AC at frequencies of 50/60 Hz.
- Coil voltage: 480V AC
- - Poles: 4
- - Contact configuration: 1 NO (main) with 1 NO auxiliary
- - Auxiliary contacts: 1NO
- - Reversing: Non-Reversing
- - Mounting style: DIN Rail, Panel
- - Electrical connection: Screw terminals
- - Embedded surge suppressor: Yes
- - Enclosure: No Enclosure
- - Frame/Series: XT, Frame C
- - Maximum voltage rating: 690V AC
- - Frequency: 50/60 Hz
- - IP rating: IP20
- - Certifications/Standards: EN 60947
- UL Listed
- CSA Certified
- IEC 60947
- CE Marked
- RoHS
- - Mechanical durability: 10,000,000 cycles
- - Dimensions (approx.): Width 4.0 in
- Height 2.75 in
- Depth 4.5 in
Additional Information
- Country of Origin: DE
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 12 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 4.50
- Package Width: 4.00
- Package Height: 2.90
- Package Weight: 1.20
