IEC Magnetic Contactor, No Auxiliary Contacts, 480V AC, 3 P, Non-Reversing, Screw MPN:XTCE095F00C
Free Shipping
In Stock
The Eaton XT IEC Magnetic Contactor is a reliable and efficient solution for a wide range of applications, including industrial control systems, machinery, and equipment. Its three-pole, non-reversing design and 480V AC coil make it suitable for high-voltage applications, while its built-in surge suppressor protects against electrical surges. The contactor's compact design and DIN Rail/panel mounting options make it ideal for space-constrained environments. With a maximum voltage of 690V AC and certifications from UL, CSA, and CE, this contactor is a trusted choice for applications requiring high reliability and durability.
Top product features:
- Non-Reversing operation
- Built-in surge suppressor
- Screw terminals for electrical connections
Top product applications:
- Industrial Automation Systems
- Electrical Panel Control Systems
- High-Voltage Power Distribution Systems
The Eaton XT IEC contactor is a three-pole, non-reversing IEC magnetic contactor (Frame F) with a 480 V AC coil. It uses screw terminals, has no auxiliary contacts, and is rated for operation up to 690 V AC. The unit includes a built-in surge suppressor and is compatible with DIN Rail and panel mounting methods. It is rated for 50/60 Hz operation and specified to operate within the temperature range of -13°F to 122°F. Dimensions are 3.54 in wide, 6.69 in high, and 5.59 in deep. It complies with applicable standards including UL, CSA, CE, EN 60947, IEC 60947
- rated IP20 without enclosure.
Key features:
- - Poles and action: 3 poles
- Non-Reversing
- - Coil voltage: 480 V AC
- Frequency: 50/60 Hz
- - Amperage ratings: Full-load inductive 95 A
- Resistive 130 A
- - Auxiliary contacts: No auxiliary contacts (0 NO/0 NC)
- - Electrical connections: Screw terminals
- - Mounting: DIN Rail, Panel
- Frame Size: F
- Dimensions: 3.54 in W x 6.69 in H x 5.59 in D
- - Enclosure/IP rating: No enclosure
- IP20
- - Maximum voltage: 690 V AC
- - Certifications: UL Listed
- CSA Certified
- CE Marked
- EN 60947
- IEC 60947
- - Durability: Mechanical 10,000,000 cycles
- Electrical operating durability 300 (AC-4 400V Ie), 800 (AC-1 400V Ie), 800 (AC-3 400V Ie)
- - Series: XT
Additional Information
- Country of Origin: DE
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 30 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 7.30
- Package Width: 7.00
- Package Height: 3.90
- Package Weight: 5.05
