IEC Magnetic Contactor, No Auxiliary Contacts, 120V AC, 3 P, Non-Reversing, Screw MPN:XTCE050D00A
Free Shipping
In Stock
The Eaton XT IEC contactor is a reliable and efficient switching solution for a wide range of applications. This full voltage non-reversing contactor is ideal for use in control circuits, motor starters, and other electrical systems where high reliability and durability are required. With its 50A amperage rating and 120V AC coil, it can handle demanding loads with ease. Its compact size and screw terminal connections make it easy to integrate into existing systems. Suitable for use in industrial, commercial, and residential settings, the Eaton XT IEC contactor is a great choice for applications that demand high performance and low maintenance.
Top product features:
- Switches within specified electrical parameters
- Non-reversing, 3-pole device
- Supports mounting on DIN rails or panels
Top product applications:
- Industrial Control Systems
- Motor Control Circuits
- Power Distribution Panels
The Eaton XT IEC contactor is an IEC magnetic contactor rated for switching within specified electrical parameters. It is a non-reversing, 3-pole device with a 120 V AC coil and does not include auxiliary contacts (if applicable), compatible with screw terminal connections within specified ratings. It conforms to standard mounting configurations as specified by the manufacturer and supports mounting on DIN rails or panels.
- Item: IEC Magnetic Contactor
- Product name: Eaton XT IEC contactor
- - Type / Action: Full voltage non-reversing contactor
- Non-Reversing
- - Poles: 3
- - Coil Voltage: 120 V AC
- - Amperage Rating: 50 A
- - Auxiliary Contacts: does not include auxiliary contacts (if applicable)
- - Contact Configuration: 0 NO, 0 NC
- - Frame Size / Series: Frame D
- XT
- - Mounting Style: DIN Rail, Panel
- - Electrical Connection: compatible with screw terminal connections within specified ratings
- - Maximum Voltage Rating: rated for operation up to 690 V AC in accordance with standards
- - Frequency: 50/60 Hz
- - IP Rating: IP20
- - Certifications / Standards: UL Listed
- CSA Certified
- IEC 60947
- EN 60947
- - Dimensions: Width 4.75 in
- Height 2 in
- Depth 5.2 in
- - Mechanical Durability: 10,000,000 cycles
Additional Information
- Country of Origin: RO
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 4.70
- Package Width: 2.30
- Package Height: 5.90
- Package Weight: 2.05
