IEC Magnetic Contactor, 1NO, 240V AC, 3 P, Non-Reversing, Screw MPN:XTCE015B10B
Free Shipping
In Stock
The Eaton XT IEC Magnetic Contactor is a reliable and efficient solution for switching power circuits in various applications. Suitable for use in industrial and commercial settings, this 3-pole device features a 1NO auxiliary contact and can handle currents up to 15A at 240V AC. Its non-reversing action and screw terminal connections make it easy to integrate into existing systems. With a high mechanical durability of 10,000,000 cycles and electrical durability of 1,200,000 cycles, this contactor is designed to provide long-lasting performance in demanding environments, making it ideal for use in manufacturing, HVAC, and other applications where reliability is crucial.
Top product features:
- The Eaton XT IEC contactor is a 3-pole device with a 1NO auxiliary contact, designed for use with coils rated at 240V AC.
- It uses screw terminals for wiring, allowing for easy and secure connections.
- The unit incorporates a surge suppression component to protect against electrical surges and spikes.
Top product applications:
- General lighting control
- Motor control
- Power distribution
The Eaton XT IEC contactor is an IEC magnetic contactor (non-reversing) used to switch power circuits. It is a 3-pole device with a 1NO auxiliary contact, designed for use with coils rated at 240V AC within specified parameters and suitable for operation at currents up to 15A within specified conditions. The unit uses screw terminals for wiring, incorporates a surge suppression component meeting relevant standards (if applicable), and is available without an enclosure
- suitability depends on installation environment.
- Amperage Rating: 15A
- - Coil Voltage: 240V AC
- - Action: Non-Reversing
- - Aux. Contact Configuration: 1NO
- - Auxiliary Contact Form: 1NO
- - Number of Poles: 3
- - Electrical Connection: Screw Terminals
- - Mounting Style: DIN Rail, Panel
- - Frame Size: B
- - Contactor Style: IEC
- - Maximum Voltage Rating: 690V AC
- - IP Rating: IP20
- - Embedded Surge Suppressor: Yes
- - Enclosure: Available without enclosure
- suitability depends on installation environment
- - Certifications/Standards: UL Listed
- CSA Certified
- IEC 60947
- EN 60947
- CE Marked
- RoHS
- - Mechanical Durability: 10,000,000 cycles
- - Electrical Durability: 1,200,000 cycles
- - Frequency: 50/60 Hz
Additional Information
- Country of Origin: RO
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 2.80
- Package Width: 2.00
- Package Height: 3.20
- Package Weight: 0.56
