IEC Magnetic Contactor, 1NO, 24V DC, 4 P, Non-Reversing, Screw MPN:XTCF045C10TD
Free Shipping
In Stock
The Eaton XT IEC Magnetic Contactor is a reliable and efficient solution for controlling electrical circuits in a variety of applications. With its 4-pole non-reversing configuration and 24V DC coil, this contactor is ideal for use in industrial automation, robotics, and other high-reliability systems. Its compact design and screw terminals make it easy to integrate into DIN Rail or panel mount configurations, while its certifications and compliance with international standards ensure safe and reliable operation. Suitable for use in environments with temperatures ranging from -13°F to 122°F, this contactor is a versatile and dependable choice for a wide range of applications.
Top product features:
- Non-Reversing Action
- Has one normally open auxiliary contact
- Rated for resistive loads up to 45 A and inductive loads up to 25 A
Top product applications:
- Industrial control systems
- Automated manufacturing lines
- Power distribution and electrical panel installations
The Eaton XT IEC contactor is an IEC magnetic contactor with 4 poles and a 24 V DC coil. It has a non-reversing configuration with one normally open auxiliary contact (1NO). It uses screw terminals and is compatible with DIN Rail or Panel mounting within the XT series, frame size C.
Key features
- - Action: Non-Reversing
- - Reversing: No
- - Poles: 4
- - Coil Voltage: 24 V DC
- - Amperage Rating: 45 A
- - Full Load Amps - Resistive: 45 A -> Rated for resistive loads up to 45 A within specified conditions.
- - Full Load Amps - Inductive: 25 A -> Rated for inductive loads up to 25 A within specified conditions.
- - Auxiliary Contacts: 1NO
- - Includes Auxiliary Contacts: Yes
- - Contact Configuration: 1 NO
- - Maximum Voltage Rating: 690 V AC -> Rated for operation at voltages up to 690 V AC under specified conditions.
- - IP Rating: IP20
- - Enclosure: No Enclosure -> Does not include an enclosure
- suitable for use in appropriate environments.
- - Mounting Style: DIN Rail, Panel
- - Terminal Connection Type: Screw
- - Frame Size: C
- - Series: XT
- - Certifications: UL Listed
- CSA Certified
- CE Marked
- EN 60947
- IEC 60947
- RoHS
- - Mechanical Durability: 10,000,000 cycles -> Has been tested for mechanical durability over multiple cycles according to testing standards.
- - Operating Temperature: -13°F to 122°F
- - Dimensions (WxHxD): 2.28 in x 3.35 in x 5.43 in
Additional Information
- Country of Origin: RO
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 4.50
- Package Width: 4.00
- Package Height: 2.80
- Package Weight: 1.40
