Cylindrical, Inductive Proximity Sensor, 12 mm Dia., Stainless Steel, Micro, 3 Wires, Unshielded MPN:E57G-12UPN4-Q
Discount: See in Cart
Free Shipping
In Stock
Free Shipping
In Stock
SKU
510-G0076091
Cylindrical, Inductive Proximity Sensor, 12 mm Dia., Stainless Steel, Micro, 3 Wires, Unshielded
This compact, cylindrical inductive proximity sensor is designed for use in a variety of applications, including industrial automation, robotics, and material handling. Its stainless steel construction and IP67 rating make it suitable for harsh environments. The sensor detects objects within a 4mm distance, operating at a frequency of 2,000 Hz, and features a 3-wire PNP output circuit. Its small size and low power consumption make it ideal for use in tight spaces and energy-efficient systems. It can be used to detect the presence or absence of objects in a variety of applications, including conveyor systems and machine tools.
Top product features:
- Cylindrical shape allows for flexible mounting options
- Inductive technology enables non-contact detection of metallic objects
- Operating frequency of 2,000 Hz provides fast response time for proximity detection
Top product applications:
- Industrial Automation
- Material Handling Systems
- Robotics Assembly
Inductive Cylindrical Proximity Sensor, Inductive, 12 mm, Proximity Sensor Power Requirement 10 to 30V DC, Unshielded, Proximity Sensor Operating Frequency 2,000 Hz, Proximity Sensor Output Circuit Type 3 Wire PNP, Max. Detecting Distance 4 mm, Proximity Sensor Electrical Connection 4 Pin Micro DC Connector, Output Mode NO, NEMA Rating 4X, IP Rating IP67, Case Material Stainless Steel, Length 69 mm, Operating Temp. Range -13 Degrees to 158 Degrees F, Max. Current Load 100mA
Additional Information
- Country of Origin: MX
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 5.10
- Package Width: 2.10
- Package Height: 2.10
- Package Weight: 0.13
Product info last updated on January 15, 2026 2:11am UTC
Category: Industrial Electrical Controls and Automation
