Pressure Switch, Standard, SPDT, 1/8" FNPT, 3.0 to 12 in H2O Range, Steel MPN:1638-10
Pressure Switch, Standard, SPDT, 1/8" FNPT, 3.0 to 12 in H2O Range, Steel
The Dwyer Instruments Pressure Switch is a reliable and efficient control solution for a variety of applications, including air conditioning and duct heater control. Its standard SPDT configuration and 1/8in FNPT connection make it easy to integrate into existing systems. With a 3.0 to 12 in H2O range and maximum pressure rating of 10 psig, this switch can handle a range of pressures and temperatures up to 110°F. Its steel housing and zinc-plated finish ensure durability and corrosion resistance, making it a great choice for demanding industrial environments.
Top product features:
- Pressure switch has a 3.0 to 12 in H2O range, allowing for precise control over a wide range of pressure settings.
- Pressure switch has a maximum differential pressure setting of 12 in wc, enabling it to accurately detect and respond to changes in pressure.
- Pressure switch is rated for 1/4 hp @ 250 V AC, 60 Hz, 15 A @ 120 to 480 V AC, 60 Hz, making it suitable for a variety of applications that require a moderate level of power.
Top product applications:
- Air Conditioning
- Duct Heater Control
- Resistive
Pressure Switch, Application Air Conditioning, Duct Heater Control, Contact Form SPDT, Electrical Connection Type Screw Terminals, Electrical Rating 1/4 hp @ 250 V AC, 60 Hz, 15 A @ 120 to 480 V AC, 60 Hz, Resistive 1/8 hp @ 125 V AC, Housing Material Steel, Housing Material Finish Zinc Plated, Housing Type Conduit Box, Input Voltage 120 to 480V AC, 125V AC, 250V AC, Maximum Differential Pressure Setting 12 in wc, Maximum Operating Temperature 110 Degrees F, Maximum Pressure Rating 10 psig
Additional Information
- Country of Origin: US
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 90 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 1.00
- Package Width: 1.00
- Package Height: 1.00
- Package Weight: 6.00
Product info last updated on February 20, 2026 2:23pm UTC
Category: Industrial Electrical Controls and Automation
