Indicating Transmitter, 6 in wc MPN:605-6
Indicating Transmitter, 6 in wc
The Magnehelic Indicating Transmitter from Dwyer Instruments is a reliable and accurate pressure measurement solution. This transmitter indicates pressure levels from 0 to 6 inches of water column with an electrical accuracy of +/-0.5% and mechanical accuracy of +/-2%. Its 4-20mA output makes it suitable for use in a variety of applications, including industrial automation, HVAC, and medical equipment monitoring. The transmitter's compact design and easy-to-read dial display make it an ideal choice for applications where space is limited. Its robust construction and NIST-traceable certification ensure reliable performance in demanding environments.
Top product features:
- Indicating Transmitter provides a 4 to 20mA output signal.
- Transmitter measures pressure from 0 to 6 in wc with an accuracy of +/-0.5 Percent (Electrical) and +/-2 Percent (Mechanical).
- Transmitter features a dial display for pressure indication.
Top product applications:
- Industrial Pressure Monitoring Systems
- Pressure Control Systems for HVAC Applications
- Process Control Systems in Pharmaceutical Manufacturing
- Indicating Transmitter, Output 4 to 20mA, Maximum Pressure 6 in wc, Minimum Pressure 0 in wc, Accuracy +/-0.5 Percent (Electrical)
- +/-2 Percent (Mechanical), Number of Wires 2, Power Required 10 to 35V DC, Process Connection Size 1/8 in, Process Connection Type NPT, Process Connection Gender Female, IP Rating Not Rated, NEMA Rating Not Rated, Series 605, Electrical Connections Screw Terminals, NIST Traceable Certificate No, Display Type Dial, Connection Location Back, Diameter 5 in
Additional Information
- Country of Origin: US
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 6.50
- Package Width: 6.00
- Package Height: 4.50
- Package Weight: 2.00
Product info last updated on February 26, 2026 8:51pm UTC
Category: Pressure and Vacuum Measuring
