2 1/2 Stnls Lm 0-30 Psi MPN:GLS405
2 1/2 Stnls Lm 0-30 Psi MPN:GLS405
Liquid Filled Gauges, 0 to 30 psi, 1/4 in NPT(M), Lower Mount
Additional Information
- UPC Code: NULL
- Country of Origin: PEOPLE'S REPUBLIC OF CHINA
- Special Order Item: Yes
- State Restricted: NO
- Minimum Order Quantity: 1
- Minimum Order UOM: EA
- Cost UOM: EA
- UOM Conversion: 1 EA = 1 EA
- Item Weight: .53
- Item Length: 4
- Item Width: 3.1
- Item Height: 1.6
- Item Cube: 19.84
Attributes
- Accuracy: 3-2-3%
- Body Material: Stainless Steel
- Case Material: Stainless Steel
- Color: Black
- Connection Size [Nom]: 1/4 in NPT(M)
- Connector Type: NPT
- Dia. [Nom]: 2-1/2 in
- Display Type: Dial
- Gauge Size: 2-1/2 in
- Lens Material: Polycarbonate
- Measuring System: Imperial
- Mounting: 1/4 in Lower Mount
- Operating Pressure [Max]: 30 psi
- Operating Temp. [Max]: 150 F
- Operating Temp. [Min]: 20 F
- Range 1: 0 to 30 psi
- Thread Size [Nom]: 1/4 in
- Type: Pressure
- Used With: Compressors; Hydraulic and Pneumatic Systems; Machine Tools; Pumps
- Wt.: 0.01 lb
Features
- Designed for long and reliable service under rugged conditions
- Typical applications include those on pumps, hydraulic and pneumatic systems, compressors and machine tools
- For other installations where it is necessary to have a gauge with a non-corrosive movement
- Glycerin filled
Product info last updated on April 14, 2026 12:03pm UTC
Category: GAUGES/GAGES
