Male to Thor Nipple, (M)NPT, 1/2, Steel MPN:P4M6

• The DIXON - P4M6 is a quick connect hose coupling for connection and disconnection without tools. It is the male plug component for a quick connect system and uses a sleeve locking mechanism to include a nitrile seal for sealed connection within specified pressure and temperature ranges. The coupling is compatible with Thor-style fittings and is constructed from steel with a zinc-plated finish for use with fluid or pneumatic lines within specified pressure and temperature ranges. Maximum working pressure: 300 psi

• operating temperature range: -40°F to 250°F (per specification).

  Key Features:


  • - Body and coupling size: 1/2 in
  • - Hose fitting size and hose inner diameter: 3/4 in
  • - Connection type: 3/4"-14 NPT male thread
  • - Coupling locking type: Sleeve
  • - Seal material: Nitrile
  • - Maximum flow rate: 7,079.21 L/min (per specification)
  • - Overall length: 2.56 in
  • - Maximum outside diameter: 1.56 in
  • - Finish: Zinc plated steel construction
  • - Application: On end of hose or pipe, suitable for water or air
  • - Does not include an integrated valve
