Male to Thor Nipple, (M)NPT, 1/2, Brass MPN:P4M8-B

• The DIXON - P4M8-B is a quick-connect style hose coupling configured for connection and disconnection without tools for water or air hose/pipe applications. It uses a sleeve locking mechanism for secure connection and features a male hose fitting compatible with Thor style interchange standards. Constructed from brass with a zinc-plated finish, this coupling accepts 1 inch inner diameter hoses and connects using a 1"-11-1/2 NPT thread size. It is rated for a maximum working pressure of 300 psi and temperatures of -40°F to 250°F (per specifications).

  Key Features:


  • - Application: End-of-hose/pipe coupling for water or air lines
  • - Coupling size and body size: 1/2 in diameter
  • - Locking type: Sleeve mechanism
  • - Material and finish: Brass construction with zinc plating
  • - Hose fitting: Male connection compatible with 1 in hose size
  • - Connection type: NPT thread (1"-11-1/2)
  • - Seal material: Nitrile
  • - Maximum flow rate: 7,079.21 liters per minute
  • - Maximum outside diameter: 1 9/16 in
  • overall length: 3 1/4 in
  • - Temperature range: -40°F to 250°F
  • - Maximum working pressure: 300 psi at 70°F
  • - Interchange type: Compatible with Thor-style fittings (per specifications)
