Parallel Gripper, Three Jaw MPN:RPC-368
Parallel Gripper, Three Jaw
The De-Sta-Co Parallel Gripper, Three Jaw, is a precision-engineered tool designed for a wide range of applications, including manufacturing, assembly, and testing. With its 1 3/8 inch stroke length and 13,344.67 N total rated grip force, this gripper provides a strong and consistent hold on parts. Its compact design and durable construction make it ideal for use in tight spaces and high-temperature environments. The gripper's accuracy and repeatability ensure reliable performance, while its IP54 rating provides protection against dust and water. Suitable for use in various industries, including aerospace, automotive, and medical device manufacturing.
Top product features:
- Three Jaw Design provides a secure grip on objects
- Maximum Operating Pressure of 100 psi allows for precise control
- Seal Material Buna-N provides a reliable seal in a wide temperature range
Top product applications:
- Automotive manufacturing: The Parallel Gripper can be used to pick and place components such as engine parts, transmission components, and other heavy machinery parts.
- Medical device assembly: The gripper's precision and high grip force make it suitable for handling delicate medical devices such as surgical instruments, implantable devices, and other equipment that requires precise handling.
- Robotics and automation: The Parallel Gripper can be integrated into robotic systems to perform tasks such as assembly, testing, and inspection of various components, including electronics, mechanical parts, and other products.
Parallel Gripper,Three Jaw, Series RPC, Stroke Length 1 3/8 in, Maximum Operating Pressure 100 psi, Minimum Operating Pressure 20 psi, Overall Width 6 1/2 in, Overall Height 4 5/8 in, Inlet Size 1/4 in, Air Inlet Type NPT, Maximum Operating Temperature 180 Degrees F, Minimum Operating Temperature -30 Degrees F, Weight 16 lb, System of Measurement Inch, Total Rated Grip Force @ 100 psi 13,344.67 N, IP Rating IP54, Seal Material Buna-N, Displacement 423.76 cc, Accuracy +/-0.002 in
Additional Information
- Country of Origin: US
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 63 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 1.00
- Package Width: 1.00
- Package Height: 1.00
- Package Weight: 5.00
