Angular Gripper, 180 Deg, Spring Closed MPN:DCT-16M-RE
Angular Gripper, 180 Deg, Spring Closed
The De-Sta-Co Angular Gripper is a versatile and reliable component ideal for use in a variety of applications, including robotics, automation, and material handling. Its 180-degree spring-closed design allows for precise control and secure grasping of objects. The gripper's compact size and lightweight construction make it easy to integrate into complex systems. With a maximum operating pressure of 7 bar and a minimum operating temperature of -35 degrees C, it can withstand demanding environments. The gripper's adjustable stroke and IP43 rating ensure reliable performance in a range of applications, from assembly and packaging to palletizing and sorting.
Top product features:
- Angular Gripper provides a 180-degree stroke.
- The gripper is spring closed.
- The gripper rotates 90 degrees.
Top product applications:
- Automotive Component Manufacturing
- Material Handling Equipment
- Robotics and Automation
Angular Gripper,180 Deg, Spring Closed, Series DCT, Open Width 81 mm, Total Stroke 180 Degrees , Maximum Operating Pressure 7 bar, Minimum Operating Pressure 4 bar, Overall Length 36 mm, Overall Width 36 mm, Overall Height 87 mm, Maximum Operating Temperature 80 Degrees C, Stroke Adjustment Increment 90 Degrees , IP Rating IP43, Gripper Rotation 90 Degrees , Minimum Operating Temperature -35 Degrees C, Inlet Size M5, Weight 0.2 kg, System of Measurement Metric
Additional Information
- Country of Origin: FR
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 42 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 1.00
- Package Width: 1.00
- Package Height: 1.00
- Package Weight: 5.00
Product info last updated on January 28, 2026 5:52pm UTC
Category: Compressors, Air Tanks and Pneumatic Parts
