Angular Gripper, 180 Deg MPN:DCT-20M
Angular Gripper, 180 Deg
The De-Sta-Co Angular Gripper, 180 Deg offers a versatile and reliable solution for gripping and rotating applications. With a 180-degree stroke and adjustable rotation, this gripper can be tailored to meet specific needs. Its robust design withstands pressures up to 7 bar and temperatures up to 80°C, making it suitable for various industries, including manufacturing, packaging, and material handling. The gripper's compact size and low weight enable easy integration into existing systems, while its IP43 rating ensures protection against dust and water. Ideal for applications requiring precise control and flexibility, this gripper enhances productivity and efficiency.
Top product features:
- 180 degree total stroke
- Gripper rotation of 90 degrees
- Stroke adjustment increment of 90 degrees
Top product applications:
- Automotive manufacturing: The angular gripper can be used to pick and place parts in an assembly line, such as engine components or dashboard trim.
- Electronics assembly: The gripper can be used to handle and assemble electronic components, such as circuit boards or connectors, in a manufacturing or repair environment.
- Packaging and shipping: The gripper can be used to handle and package small items, such as electronics or pharmaceuticals, in a warehouse or shipping environment.
Angular Gripper,180 Deg, Series DCT, Open Width 99 mm, Total Stroke 180 Degrees , Maximum Operating Pressure 7 bar, Minimum Operating Pressure 3 bar, Overall Length 42 mm, Overall Width 42 mm, Overall Height 89 mm, Maximum Operating Temperature 80 Degrees C, Stroke Adjustment Increment 90 Degrees , IP Rating IP43, Gripper Rotation 90 Degrees , Minimum Operating Temperature -35 Degrees C, Inlet Size M5, Weight 0.28 kg, System of Measurement Metric, Force @100 psi 25 lb
Additional Information
- Country of Origin: FR
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 42 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 1.00
- Package Width: 1.00
- Package Height: 1.00
- Package Weight: 5.00
Product info last updated on February 3, 2026 12:27pm UTC
Category: Compressors, Air Tanks and Pneumatic Parts
