Angular Gripper, 180 Deg, Spring Closed MPN:DCT-20M-RE
Angular Gripper, 180 Deg, Spring Closed
The De-Sta-Co Angular Gripper is a versatile and reliable component designed for a wide range of applications. Its 180-degree spring-closed mechanism provides a secure grip on various materials, making it ideal for use in robotics, automation, and assembly lines. The gripper's compact size and adjustable stroke allow for precise control and flexibility in tight spaces. Suitable for temperatures ranging from -35°C to 80°C, it can be used in various industries, including manufacturing, packaging, and material handling. Its robust construction and IP43 rating ensure durability and resistance to environmental factors, making it a reliable choice for demanding applications.
Top product features:
- 180 degree angular movement
- Spring closed design
- 90 degree stroke adjustment increment
Top product applications:
- Material Handling and Automation
- Robotics and Machine Vision
- Medical Device Assembly
Angular Gripper,180 Deg, Spring Closed, Series DCT, Open Width 180 mm, Total Stroke 180 Degrees , Maximum Operating Pressure 7 bar, Minimum Operating Pressure 4 bar, Overall Length 42 mm, Overall Width 76 mm, Overall Height 104 mm, Maximum Operating Temperature 80 Degrees C, Stroke Adjustment Increment 90 Degrees , IP Rating IP43, Gripper Rotation 90 Degrees , Minimum Operating Temperature -35 Degrees C, Inlet Size M5, Weight 0.33 kg, System of Measurement Metric
Additional Information
- Country of Origin: FR
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 42 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 1.00
- Package Width: 1.00
- Package Height: 1.00
- Package Weight: 5.00
Product info last updated on February 2, 2026 5:11pm UTC
Category: Compressors, Air Tanks and Pneumatic Parts
