Angular Gripper, 180 Deg, Spring Closed MPN:CT-40M-RE
Angular Gripper, 180 Deg, Spring Closed
The De-Sta-Co Angular Gripper is a versatile and reliable component ideal for applications requiring precise angular movement. With a 180-degree stroke and spring-closed design, this gripper is perfect for tasks such as material handling, assembly, and testing. Its compact size and adjustable stroke make it suitable for use in confined spaces and a variety of industries, including automotive, aerospace, and medical. The gripper's high operating pressure and temperature range ensure consistent performance in demanding environments, making it an excellent choice for manufacturers seeking a reliable and efficient solution for angular gripping applications.
Top product features:
- 180 degree angular motion
- Spring closed design
- Rotates 90 degrees
Top product applications:
- Packaging machinery
- Material handling equipment
- Automotive manufacturing
Angular Gripper,180 Deg, Spring Closed, Series CT, Open Width 149 mm, Total Stroke 180 Degrees , Maximum Operating Pressure 7 bar, Minimum Operating Pressure 4 bar, Overall Length 66 mm, Overall Width 66 mm, Overall Height 165.5 mm, Maximum Operating Temperature 80 Degrees C, Stroke Adjustment Increment 90 Degrees , IP Rating IP43, Gripper Rotation 90 Degrees , Minimum Operating Temperature -35 Degrees C, Inlet Size 1/8 in, Air Inlet Type G, Weight 1.39 kg, System of Measurement Metric
Additional Information
- Country of Origin: FR
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 42 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 1.00
- Package Width: 1.00
- Package Height: 1.00
- Package Weight: 5.00
Product info last updated on February 17, 2026 4:47pm UTC
Category: Compressors, Air Tanks and Pneumatic Parts
