Angular Gripper, 180 Deg, Spring Closed MPN:DCT-25M-RE
Angular Gripper, 180 Deg, Spring Closed
The De-Sta-Co Angular Gripper is a versatile and reliable solution for applications requiring precise angular movement. With a 180-degree stroke and spring-closed design, this gripper is ideal for use in assembly, testing, and packaging applications. Its compact size and adjustable stroke make it suitable for a wide range of industries, including automotive, aerospace, and medical device manufacturing. The gripper's high operating pressure and temperature ratings ensure reliable performance in demanding environments, while its IP43 rating provides protection against dust and moisture. Its compact size and adjustable stroke make it a valuable addition to any production line.
Top product features:
- 180 Degree Angular Movement
- Spring-Closed Design
- Stroke Adjustment Increment of 90 Degrees
Top product applications:
- Material Handling Equipment
- Automotive Assembly Lines
- Aerospace Manufacturing
Angular Gripper,180 Deg, Spring Closed, Series DCT, Open Width 118 mm, Total Stroke 180 Degrees , Maximum Operating Pressure 7 bar, Minimum Operating Pressure 4 bar, Overall Length 50 mm, Overall Width 50 mm, Overall Height 127 mm, Maximum Operating Temperature 80 Degrees C, Stroke Adjustment Increment 90 Degrees , IP Rating IP43, Gripper Rotation 90 Degrees , Minimum Operating Temperature -35 Degrees C, Inlet Size M5, Weight 0.57 kg, System of Measurement Metric
Additional Information
- Country of Origin: FR
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 42 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 1.00
- Package Width: 1.00
- Package Height: 1.00
- Package Weight: 5.00
Product info last updated on January 11, 2026 6:37pm UTC
Category: Compressors, Air Tanks and Pneumatic Parts
