Parallel Gripper, 2 Jaw, Lg Str MPN:DPL-2520
Parallel Gripper, 2 Jaw, Lg Str
The De-Sta-Co Parallel Gripper, Series DPL, is a versatile and reliable component for a variety of applications, including material handling, assembly, and testing. Its large stroke length and maximum operating pressure of 100 psi allow for secure gripping and handling of a range of materials. The gripper's accuracy and repeatability ensure consistent results, while its temperature range and IP54 rating make it suitable for use in a variety of environments. Ideal for use in manufacturing, packaging, and quality control settings, this gripper offers a reliable solution for companies requiring precision and control in their operations.
Top product features:
- 2 Jaw design allows for secure and stable gripping of objects
- Stroke Length of 1 5/8 in enables precise and controlled movement
- Maximum Operating Pressure of 100 psi enables high-force gripping applications
Top product applications:
- Automotive industry for assembly and testing of parts
- Medical device manufacturing for precise component handling
- Aerospace industry for gripping and positioning of sensitive components
Parallel Gripper, 2 Jaw, Lg Str, Series DPL, Stroke Length 1 5/8 in, Maximum Operating Pressure 100 psi, Minimum Operating Pressure 30 psi, Overall Length 2 1/4 in, Overall Width 6 in, Overall Height 3 in, Inlet Size M5, Maximum Operating Temperature 180 Degrees F, Minimum Operating Temperature -4 Degrees F, Weight 3.04 lb, System of Measurement Inch, Total Rated Grip Force @ 100 psi 809.57 N, IP Rating IP54, Displacement 39.1 cc, Accuracy +/-0.003 in, Repeatability +/-0.001 in
Additional Information
- Country of Origin: FR
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 42 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 1.00
- Package Width: 1.00
- Package Height: 1.00
- Package Weight: 5.00
Product info last updated on January 16, 2026 8:16am UTC
Category: Compressors, Air Tanks and Pneumatic Parts
