Jaw Coupling Insert, L099/L100, Hytrel MPN:29HZ15
Discount: See in Cart
Free Shipping
In Stock
Free Shipping
In Stock
SKU
510-G6112057
Jaw Coupling Insert, L099/L100, Hytrel
The Dayton Hytrel Spider Insert is a reliable and versatile jaw coupling solution for applications requiring close coupling and high performance. With a maximum speed of 7,000 RPM and a maximum torque of 792 in-lb, this insert is suitable for a wide range of applications, including pumps, motors, and gearboxes. Its fail-safe design ensures safe operation even in the event of misalignment or failure. The Hytrel material provides excellent durability and resistance to wear and tear, making it an ideal choice for applications requiring high reliability and minimal maintenance.
Top product features:
- Hytrel Spider Insert provides high torque capacity with a maximum torque of 792 in-lb.
- The product allows for parallel misalignment of up to 0.015 in, enabling flexible installation.
- The insert features a fail-safe design, ensuring secure coupling even in the event of a failure.
Top product applications:
- Close Coupling L-Type
- Fail Safe Yes
- For Minimum Hub Bore 7/16 in
Hytrel Spider Insert, Coupling Size L099, L100, Outside Diameter 2 33/64 in, System of Measurement Inch, Maximum Speed 7,000 RPM, Horsepower @ 100 RPM 1.8 hp, Spider Material Hytrel, Maximum Torque 792 in-lb, Parallel Misalignment 0.015 in, Durometer Hardness 55D, Axial Motion 0.02 mm, Angular Misalignment 0.5 Degrees , For Minimum Hub Bore 7/16 in, Application Close Coupling L-Type, Color Tan, Compatible Hub Manufacturer Part Number L099, L100, Fail Safe Yes, For Maximum Hub Bore 1 3/8 in
Additional Information
- Country of Origin: CN
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 2.60
- Package Width: 2.60
- Package Height: 0.70
- Package Weight: 0.07
Product info last updated on February 14, 2026 5:14pm UTC
Category: Bearings, V-belts and Power Transmission Equipment
