IEC Magnetic Contactor, No Auxiliary Contacts, 24V AC, 4 P, Non-Reversing MPN:6EAY5
Free Shipping
In Stock
The DAYTON IEC Magnetic Contactor is a reliable and efficient electromagnetically operated switch designed for use in various applications. With a 24V AC coil and four poles, it provides non-reversing operation and can handle high inductive and resistive loads. Suitable for use in industrial, commercial, and residential settings, this contactor is ideal for controlling motors, pumps, and other equipment. Its compact size and robust design make it an excellent choice for applications where space is limited. By providing reliable and efficient switching, the DAYTON IEC Magnetic Contactor helps to increase productivity and reduce downtime, making it a valuable addition to any electrical system.
Top product features:
- Operates with a 24 V AC coil
- Has four poles with non-reversing operation
- Supports up to 25 A full load current inductive and 40 A full load current resistive
Top product applications:
- Industrial Automation Control Panels
- Motor Control Centers
- HVAC Control Systems
The DAYTON IEC Magnetic Contactor, No Auxiliary Contacts, 24V AC, 4P, Non-Reversing is an IEC-style, electromagnetically operated switch rated for operation within the specified electrical parameters. It uses a 24 V AC coil to operate and has four poles with non-reversing operation
- includes auxiliary contacts as specified.
- Action: Non-Reversing
- - Coil Voltage: 24 V AC
- - Coil Volts: 24 V AC
- - Contactor Style: IEC
- - Depth: 3.75 in
- - Embedded Surge Suppressor: No
- - Enclosure NEMA Rating: Does not include an enclosure
- - Frequency: 50/60 Hz
- - Full Load Amps-Inductive: 25 A
- - Full Load Amps-Resistive: 40 A
- - Full Load Current - Inductive: 25 A
- - Full Load Current - Resistive: 40 A
- - HP @ 1 Phase - 120V: 2 hp
- - HP @ 1 Phase - 230V: 3 hp
- - HP @ 1 Phase - 240V: 3 hp
- - Height: 2.2 in
- - Includes Auxiliary Contacts: Yes
- - Item: IEC Magnetic Contactor
- - NEMA Enclosure Rating: Does not include an enclosure
- - Number of Auxillary Contacts: 4
- - Number of Normally Closed Main Contacts: 2
- - Number of Normally Open Main Contacts: 2
- - Number of Poles: 4
- - Standards: CSA, UL Listed
- - Width: 2.2 in
- - Reversing: No
- - Reversing Capability: Non-Reversing
- - Special Features: Main Contact Configuration 2NC/2NO
- - Overall Depth: 3.75 in
- - Overall Height: 2.2 in
- - Overall Width: 2.2 in
- - Hz: 50/60
- - Frequency: 50/60 Hz
Additional Information
- Country of Origin: IN
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 4.30
- Package Width: 3.70
- Package Height: 2.50
- Package Weight: 0.45
- California Prop 65 Warning: WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
