Brake, Motor, 3 Ft Lb MPN:1L388
Discount: See in Cart
Free Shipping
In Stock
Free Shipping
In Stock
SKU
510-G1841822
Brake, Motor, 3 Ft Lb
This Dayton C-Face Magnetic Disc Brake is a reliable and efficient solution for applications requiring precise braking and clutching. Designed for use with single-phase motors, it provides a static torque of 3 ft-lb, making it ideal for applications such as conveyor systems, packaging machinery, and material handling equipment. The brake's NEMA C Face motor frame and totally enclosed enclosure ensure durability and protection from the elements. With a lead time of just one day, this brake can be easily integrated into your system, providing a reliable and efficient braking solution for a wide range of industrial applications.
Top product features:
- Clutch/Brake Type C-Face Magnetic Disc
- Operating at 50 Hz, this product can be powered by 110/208-220V AC, and at 60 Hz, it can be powered by 115/208-230V AC
- Totally Enclosed Enclosure Type provides protection from environmental factors
Top product applications:
- Machine tool applications
- Industrial automation systems
- Material handling equipment
Brake, Clutch/Brake Type C-Face Magnetic Disc, Coil Voltage 110/208-220V AC @ 50 Hz, 115/208-230V AC @ 60 Hz, Operating Voltage 110/208-220V AC @ 50 Hz, 115/208-230V AC @ 60 Hz, Enclosure Type Totally Enclosed, Static Torque 3 ft-lb, Motor Frame Designation 56C NEMA, Horsepower @ RPM 1 hp @ 1725 RPM, 2 hp @ 3450 RPM, Shaft Diameter 5/8 in, Maximum Speed 3,450 RPM, Mounting Location Between Motor and Reducer, NEMA C Face Motor, For Use With Single Phase Motors, When Wired per Instructions
Additional Information
- Country of Origin: US
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 7.50
- Package Width: 7.50
- Package Height: 9.00
- Package Weight: 13.50
