IEC Magnetic Contactor, 1NO, 240V AC, 3 P, Non-Reversing, Screw MPN:6EAW3
Free Shipping
In Stock
The DAYTON IEC Magnetic Contactor is a reliable and efficient switching device designed for a wide range of applications. Rated for 240V AC and 3-pole, non-reversing operation, it can handle inductive loads up to 32A and resistive loads up to 50A. Suitable for use in industrial control systems, the contactor features a screw terminal connection and a single normally open (NO) auxiliary contact. Its compact design makes it ideal for use in limited spaces, and its compliance with CSA and UL standards ensures safe and reliable operation. Perfect for use in motor control, lighting, and HVAC applications.
Top product features:
- Operates within specified electrical parameters to provide a reliable switching solution.
- Has a non-reversing action to ensure consistent and predictable operation.
- Includes 1 NO auxiliary contact for additional control and functionality.
Top product applications:
- Motor Control Systems
- Power Distribution Panels
- HVAC Control Systems
The DAYTON IEC Magnetic Contactor is an IEC-standard, electrically operated switching device rated for operation within specified electrical parameters.
- Item: IEC Magnetic Contactor (3-pole, non-reversing)
- - Coil Voltage: 240 V AC
- - Action: Non-Reversing
- - Reversing: No
- - Auxiliary Contacts: 1 NO (1 auxiliary contact)
- - Terminal Connection: Screw
- - Includes Auxiliary Contacts: Yes
- - Depth x Height x Width: 3.96 in x 2.2 in x 2.2 in
- - Enclosure: Does not include an enclosure
- ensure proper installation according to applicable standards
- - Embedded Surge Suppressor: No
- - Frequency: 50/60 Hz
- - Standards: Complies with applicable CSA and UL standards
- - Full Load Amps: Inductive 32 A
- Resistive 50 A
- - Full Load Current: Inductive 32 A
- Resistive 50 A
- - HP @ 1 Phase: 120 V -> 2 hp
- 230 V -> 5 hp
- 240 V -> 5 hp
- - HP @ 3 Phase: 208 V -> 10 hp
- 240 V -> 10 hp
- 480 V -> 20 hp
- 575 V -> 25 hp
