HVAC Motor, 1/30 HP, 3000 rpm, 230V, 3.3 MPN:71214610M
HVAC Motor, 1/30 HP, 3000 rpm, 230V, 3.3
This Dayton HVAC motor is a reliable and efficient solution for a variety of applications, including residential and commercial heating and cooling systems. Its 1/30 HP rating and 3000 rpm make it suitable for low-power ventilation and circulation needs. The motor's single-phase design and shaded pole construction provide a quiet and durable operation. With a maximum ambient temperature of 40 degrees C, it can withstand harsh environments. The motor's compact design and steel frame make it easy to install and maintain. Ideal for use in attics, crawl spaces, and other areas where a compact motor is required.
Top product features:
- Shaded Pole Motor Design
- Single Phase Operation
- Continuous Duty Cycle
Top product applications:
- Small residential HVAC systems
- Commercial air conditioning units
- Packaged rooftop air handlers
HVAC Motor, Single Phase, Motor Design Shaded Pole, 1/30 hp HP, Nameplate RPM 3,000 RPM, No. of Speeds 1, Voltage 230V AC, 0.60 A Full Load Amps, 3.3 Frame, Output Watts 25 W, 60 Hz Hz, Usable @ 208V Not Usable at 208V, Usable @ 200V Not Usable at 200V, Motor Service Factor 1, Motor Thermal Protection Auto, Ins. Class B, Duty Cycle Continuous, Max. Ambient Temp. 40 Degrees C, Motor Shaft Rotation CWSE, Motor Enclosure Design Open Air Over, Motor Mounting Type Stud, Motor Frame Material Steel
Additional Information
- Country of Origin: MX
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 44.40
- Package Width: 22.80
- Package Height: 33.00
- Package Weight: 21.60
Product info last updated on February 5, 2026 7:49am UTC
Category: Motors
