Solid State Relay, 1 Phase, Quick Connect, Panel, MOSFET MPN:EL100D5-05
Solid State Relay, 1 Phase, Quick Connect, Panel, MOSFET
This Solid State Relay from Crydom is a reliable and efficient solution for controlling DC power in a wide range of applications. With a quick connect feature and heat sink included, it can handle maximum output currents of up to 5A. Suitable for use in industrial control systems, automation, and power supply applications, this relay offers a high level of safety and reliability. Its compact design and CE, RoHS, and UL certifications make it an ideal choice for various industries, including manufacturing, healthcare, and energy. Its versatility and performance make it a valuable addition to any system.
Top product features:
- Quick Connect Electrical Connection allows for easy attachment and detachment of wires.
- Heat Sink Included provides improved thermal management and reliability.
- Maximum Output Current of 5 A enables the relay to handle a wide range of load requirements.
Top product applications:
- Industrial Control Systems
- Solar Panel Systems
- Medical Equipment Control
Solid State Relay, Electrical Connection Quick-Connect, Heat Sink Included, Input Current 27 mA, Input Voltage 4 to 8V DC, Maximum Output Current with Heat Sink 5 A, Maximum Output Current without Heat Sink 5 A, Output Switching Mode Not Applicable, Output Voltage Range 3 to 100V DC, Standards CE Certified, RoHS Compliant, TUV Certified, UL Listed, Switch Component Type MOSFET, Current Type DC, Finger Safe No, Mounting Style Panel, Switch Configuration Form A, Voltage Type DC Output
Additional Information
- Country of Origin: MX
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 6.20
- Package Width: 4.50
- Package Height: 4.70
- Package Weight: 0.20
- California Prop 65 Warning: WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
Product info last updated on February 16, 2026 10:54am UTC
Category: Industrial Electrical Controls and Automation
