Dual Solid State Relay, 2 Phase, Screw Clamp, Panel, SCR MPN:CD2450W3V
Dual Solid State Relay, 2 Phase, Screw Clamp, Panel, SCR
This dual solid state relay is designed for high-current applications, with a maximum output current of 50A with a heat sink. Ideal for use in industrial control systems, it features zero-crossing switching for minimal interference and a wide output voltage range of 24-280V AC. The screw clamp electrical connection and panel mounting style make it easy to integrate into a variety of systems. Suitable for applications such as motor control, lighting, and HVAC systems, this relay offers reliable and efficient switching performance. Its compact size and low input current of 10mA make it a versatile solution for demanding industrial environments.
Top product features:
- Dual Solid State Relay
- Switches AC output voltage in zero crossing mode
- Has a maximum output current of 50A with a heat sink
Top product applications:
- Industrial Control Systems
- Motor Speed Control
- Power Conditioning and Power Factor Correction
Dual Solid State Relay, Electrical Connection Screw Clamp, Heat Sink Not Included, Input Current 10 mA, Input Voltage 4 to 32V DC, Maximum Output Current with Heat Sink 50 A, Maximum Output Current without Heat Sink Not Recommended, Output Switching Mode Zero Crossing, Output Voltage Range 24 to 280V AC, Standards UL 508, Switch Component Type SCR, Current Type AC, Finger Safe No, Mounting Style Panel, Switch Configuration Form A, Voltage Type AC Output, Body Depth 0.8 in, Body Height 0.79 in
Additional Information
- Country of Origin: MX
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 2.30
- Package Width: 1.90
- Package Height: 1.50
- Package Weight: 0.25
- California Prop 65 Warning: WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
Product info last updated on March 19, 2026 10:05am UTC
Category: Industrial Electrical Controls and Automation
