Solid State Relay, 1 Phase, Screw Clamp, DIN Rail, SCR MPN:CKRD4820
Solid State Relay, 1 Phase, Screw Clamp, DIN Rail, SCR
This Solid State Relay from Crydom is a reliable and efficient solution for controlling high-voltage applications. With a maximum output current of 20A and a wide output voltage range of 48-530V AC, it can handle a variety of tasks, including motor control, lighting, and HVAC systems. The zero-crossing switching mode ensures smooth and quiet operation, while the integral heat sink provides reliable heat dissipation. This SCR relay is perfect for use in industrial automation, building control, and other high-voltage applications where reliability and efficiency are crucial. Its compact design and CE certification make it an ideal choice for a wide range of industries.
Top product features:
- Solid State Relay with zero crossing switching mode for reduced electromagnetic interference and improved switching reliability
- Integral heat sink for increased maximum output current and improved thermal management
- Input current range of 8 to 12 mA for flexibility in control circuit design and reduced current consumption
Top product applications:
- Lighting control systems
- Motor control systems
- Power supply control systems
Solid State Relay, Electrical Connection Screw Clamp, Heat Sink Integral, Input Current 8 to 12 mA, Input Voltage 4 to 32V DC, Maximum Output Current with Heat Sink 20 A, Maximum Output Current without Heat Sink 20 A, Output Switching Mode Zero Crossing, Output Voltage Range 48 to 530V AC, Standards CE Certified, CSA LR81689, Designed in accordance with the requirements of IEC 62314, RoHS Compliant, UR E116950, VDE 129156, Switch Component Type SCR, Current Type DC, Finger Safe Yes
Additional Information
- Country of Origin: MX
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 4.30
- Package Width: 4.40
- Package Height: 1.20
- Package Weight: 0.65
- California Prop 65 Warning: WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
Product info last updated on January 15, 2026 4:57am UTC
Category: Industrial Electrical Controls and Automation
