20PC 118 Degree General Purpose Jobber Lengh Drill Set Chicago-Latrobe 150-TN TiN HSS No 61-No 80 MPN:69897
Free Shipping
In Stock
Elevate your drilling capabilities with the Chicago-Latrobe 150-TN TiN HSS Jobber Length Drill Set. This 20-piece set features 118-degree point angle drill bits made from high-speed steel with a titanium nitride (TiN) coating for enhanced durability and corrosion resistance. Ideal for general-purpose drilling applications, this set is suitable for a variety of industries, including aerospace, automotive, and construction. Its compact size and lightweight design make it easy to store and transport, while its precision-crafted drill bits deliver accurate, reliable results. Perfect for professionals and DIY enthusiasts alike, this drill set is a valuable addition to any toolbox.
Top product features:
- 20PC 118 Degree General Purpose Jobber Length Drill Set has 20 drill bits.
- The drill bits have a 118 degree point angle.
- The drill bits are made of high speed steel with a TiN finish.
Top product applications:
- Drilling metal pipes and tubing
- Drilling wood and other soft materials
- Drilling holes in metal plates and sheets
The CHICAGO-LATROBE 69897 is a jobber length drill bit set consisting of 20 pieces made from high speed steel with a general-purpose grade. The bits have a conventional point and a right-hand spiral direction
- they are suitable for use on aluminum, cast iron, and steel when used with appropriate drilling equipment and operating parameters. This set includes sizes from #80 to #61 with varying overall lengths from 3/4 inch up to 1 5/8 inches and comes housed in a metal drill index for organization and storage.
Key Features:
- - Drill bit material: High speed steel (general-purpose grade)
- - Drill bit size range: #80 (smallest) to #61 (largest)
- - Number of bits: 20 pieces with 2-flute spiral design
- - Length: Jobber length with overall lengths from 3/4" to 1 5/8"
- - Point type: Conventional 118-degree point angle
- - Shank type: Straight with diameter of 27/2000 inches
- - Spiral direction: Right hand with helix angles between 21° and 34°
- - Primary material applications: Aluminum, cast iron, and steel (ISO K, N, P)
- - Measurement system: Wire gauge sizing
- - Standard: ASME B94.11M-1993
- - Includes a metal drill bit index case
Additional Information
- Country of Origin: US
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 3.60
- Package Width: 2.30
- Package Height: 0.50
- Package Weight: 0.06
