Air Operated Valve, 2-Way, NC, 1/2 In, FNPT MPN:D53CWSCBB01-E1
Air Operated Valve, 2-Way, NC, 1/2 In, FNPT
This 2-way air operated valve is a reliable solution for various industrial applications, including water treatment, oil and gas, and chemical processing. Its pneumatic actuation allows for precise control and effortless operation, while its bronze body and Buna-N diaphragm ensure durability and resistance to corrosion. With a maximum operating pressure of 250 psi and a temperature range of up to 180°F, this valve can handle demanding environments. Its normally open design and high flow rate make it ideal for applications where consistent flow is critical, such as in irrigation systems, water supply lines, and process control.
Top product features:
- Pneumatically actuated diaphragm valve controls flow of media through 1/2 in connections.
- Normally open valve deactivates to close flow in the absence of air pressure.
- Bronze body and Buna-N diaphragm and seal materials are resistant to corrosion and wear.
Top product applications:
- Air Operated Valve for controlling the flow of air in industrial pneumatic systems
- Oil Service Valve for controlling the flow of oil in hydraulic systems
- Water Treatment Valve for regulating water flow in municipal or industrial water treatment plants
Pneumatically Actuated Diaphragm Valve, Coefficient of Volume (Cv) 2.5, Nominal Valve Size 1/2 in, Actuator Air Port Connection 1/8 in FNPT, Connection Type - Side 1 NPTF, Connection Type - Side 2 NPTF, For Media Air, Oil, Water, Diaphragm Material Buna-N, Operating Temperature - Maximum 180 Degrees F, Maximum Pressure - Operating 250 psi, Valve Deactivated State Normally Open (NO), Body Material Bronze, Diaphragm Valve Type 2-Way, Seal Material Buna-N, Overall Length 1.94 in
Additional Information
- Country of Origin: US
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 4.00
- Package Width: 3.50
- Package Height: 6.10
- Package Weight: 2.95
Product info last updated on February 4, 2026 11:01am UTC
Category: Compressors, Air Tanks and Pneumatic Parts
