Pallet Lifter, Std Fixed Fork, 3T, L42" MPN:90-3-42
The Caldwell Pallet Lifter is a heavy-duty solution for efficiently handling pallets in a variety of industries. With a maximum load capacity of 6,000 lb and fixed fork spacing, this pallet lifter is perfect for applications where precision and stability are crucial. Its compact design and adjustable fork height make it easy to maneuver in tight spaces, reducing the risk of accidents and damage. Suitable for warehouses, distribution centers, and manufacturing facilities, this pallet lifter is an essential tool for improving productivity and streamlining logistics. Its durability and reliability ensure years of trouble-free operation.
Top product features:
- Maximum Load Capacity 6,000 lb
- Fork Adjustability Fixed Forks
- Fork Height 2 1/2 in
Top product applications:
- Warehouse operations
- Material handling in manufacturing facilities
- Distribution centers
The Caldwell 90-3-42 is a below-the-hook pallet lifter with a fixed-fork design and a maximum load capacity of 6,000 lb (3 ton). It allows an overhead crane to handle palletized loads via two fork tines, attaching to the crane hook through a bail.
The forks are 42 in. long, 4 1/2 in. wide, and 2 1/2 in. high, set at a 16 in. spacing, with a throat height of 48 in. and an overall width of 25 in. Maximum headroom is 62 in., and the bail center of gravity is 21 in. The bail opening measures 6 1/8 in. wide by 7 in. high.
The lifter is built to ASME standards.
Key Features:
- - MFR #: 90-3-42 ·
- Brand: Caldwell
- - Type: Pallet lifter (below-the-hook) ·
- Fork adjustability: Fixed
- - Maximum load capacity: 6,000 lb (3 ton)
- - Fork length: 42 in. ·
- Fork width: 4 1/2 in. ·
- Fork height: 2 1/2 in.
- - Fork spacing: 16 in. ·
- Throat height: 48 in.
- - Overall width: 25 in. ·
- Maximum headroom: 62 in.
- - Bail center of gravity: 21 in. ·
- Bail opening: 6 1/8 in. W × 7 in. H ·
- Bail inside: 7 in. L × 6 1/8 in. W
- - Bail height: 1 1/2 in. ·
- Material above bail opening: 1 1/2 in.
- - Standards: ASME
- - Country of origin: United States
Additional Information
- Country of Origin: US
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 32 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 48.00
- Package Width: 40.00
- Package Height: 70.00
- Package Weight: 814.00
