Portable Gantry Crane, 4000 lb., 14 ft. 4" MPN:H90-2-12/14

• The Caldwell H90-2-12/14 is a portable steel gantry crane with a 4,000 lb load capacity. It has an adjustable span — 14 ft 11 in. overall (14 ft 4 in. clear) at this configuration — and a fixed height of 12 ft under the beam, with a maximum overall height of 12.8 ft. The frame depth is 6 ft 6 in.

  The crane rolls on four swivel steel casters (8 in. diameter) and is rated mobile under load. The beam is a 10 in. I-beam with a 4.7 in. flange width, and the legs attach by clamp-on connection. Construction is steel with a yellow enamel finish.

  The unit ships with two supports, the I-beam, and assembly hardware. It is built to AISC, CMAA, and OSHA specifications.

  Key Features:

  • - MFR #: H90-2-12/14 ·
  • Brand: Caldwell
  • - Type: Portable gantry crane ·
  • Mobility: 4 swivel casters, mobile under load
  • - Load capacity: 4,000 lb
  • - Span: adjustable ·
  • Overall span: 14 ft 11 in. (range 12–15.5 ft) ·
  • Clear span: 14 ft 4 in. (range 12–14.3 ft)
  • - Height: fixed ·
  • Height under beam: 12 ft ·
  • Max overall height: 12.8 ft
  • - Frame depth: 6 ft 6 in. (78 in.)
  • - I-beam: 10 in. height, 4.7 in. flange width
  • - Casters: (4) swivel, steel, 8 in. dia., 3 in. wide
  • - Leg connection: Clamp-on ·
  • Rotating legs: No
  • - Material: Steel ·
  • Finish: Enamel ·
  • Color: Yellow
  • - Includes: (2) supports, I-beam, assembly hardware
  • - Standards: AISC, CMAA, OSHA
  • - Country of origin: United States
