One-Hole Compression Lug, 3/0 AWG Max, 5/8 in Stud, Long Barrel, Copper, None
This One-Hole Compression Lug is a reliable and efficient solution for electrical connections. Designed for use with 3/0 AWG wire, it features a long barrel and braze-style construction for secure crimping. With a maximum operating temperature of 302°F and a voltage rating of 600V, it's suitable for a variety of applications, including industrial and commercial electrical systems. Its compact size and lightweight design make it easy to install and handle. Perfect for use in harsh environments, this lug provides a secure and reliable connection, ensuring the integrity of electrical systems and prolonging equipment lifespan.
Top product features:
- Crimping termination style allows for secure connection to wire
- Long barrel design provides increased wire capacity
- Tin contact finish ensures reliable and durable electrical connection
Top product applications:
- Wire Harness Assembly
- Automotive Electrical System
- Industrial Control Panel Wiring
Ring Terminal, Insulation Color Bare, Insulation Coverage None, Insulation Material None, Maximum Operating Temperature 302 Degrees F, Maximum Voltage 600 V, Minimum Wire Size 3/0 AWG, Maximum Wire Size 3/0 AWG, Termination Style Crimp, Tongue Width 1.14 in, Contact Finish Tin, Contact Material Copper, Standards UL 467, Barrel Length 0.79 in, Barrel Outside Diameter 0.79 in, Barrel Size Long, Barrel Style Brazed, Compatible Grainger Part Number 22P219, 22P221
Additional Information
- Country of Origin: TW
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 5.00
- Package Width: 9.00
- Package Height: 0.79
- Package Weight: 0.10
Product info last updated on March 29, 2026 9:14am UTC
Category: Electrical Connectors
