Mechanical Lug, 250 kcmil Max, 4 Conductor, 4 Hole, 1/2 in Stud, Aluminum MPN:K4A29U4N
Discount: See in Cart
Free Shipping
In Stock
Free Shipping
In Stock
SKU
510-G4663635
Mechanical Lug, 250 kcmil Max, 4 Conductor, 4 Hole, 1/2 in Stud, Aluminum
The Burndy Mechanical Lug is a reliable and efficient solution for connecting aluminum and copper conductors in a variety of applications. With a maximum operating temperature of 194°F and a maximum voltage of 600V, this lug is suitable for use in electrical distribution systems, industrial settings, and construction projects. Its 4-conductor design and 1/2 in stud size make it ideal for use in applications requiring multiple connections. The lug's durable aluminum body and hex socket head ensure a secure and easy installation process, making it a valuable tool for electricians and contractors.
Top product features:
- Connects 4 stranded copper wires with a maximum size of 250 kcmil and aluminum conductors
- Accepts a 1/2 in stud for secure attachment
- Operates at a maximum temperature of 194 Degrees F and a maximum voltage of 600 V
Top product applications:
- Bus Bar Connectors
- Electrical Panel Connectors
- Cable Connectors for Aluminum and Copper Conductors
Mechanical Connector, For Conductor Material Aluminum, Copper, For Stranded Copper Wire Size - Minimum 6 AWG, For Stranded Copper Wire Size - Maximum 250 kcmil, For Stud Size 1/2 in, Head Style Hex Socket, Number of Holes 4, Hole Diameter 0.56 in, Hole Spacing 1.75 in, Body Material Aluminum, Maximum Operating Temperature 194 Degrees F, Maximum Voltage 600 V, Number of Conductors 4, Number of Terminations 4, Tongue Length 3.16 in, Tongue Width 3.69 in, Tongue Thickness 0.31 in
Additional Information
- Country of Origin: US
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 4.00
- Package Width: 3.70
- Package Height: 1.20
- Package Weight: 0.65
Product info last updated on February 19, 2026 1:49pm UTC
Category: Electrical Connectors
