Three-Phase General Purpose Motor, 3 HP, 184TC Frame, 208-230/460V AC Voltage, 3, 450 Nameplate RPM MPN:VEM3610T
Discount: See in Cart
Free Shipping
In Stock
Free Shipping
In Stock
SKU
510-G8439837
Three-Phase General Purpose Motor, 3 HP, 184TC Frame, 208-230/460V AC Voltage, 3, 450 Nameplate RPM
This 3 HP three-phase general purpose motor from BALDOR-RELIANCE is designed for heavy-duty applications in various industries. With a nameplate RPM of 3,450 and a frame size of 184TC, it provides efficient power for continuous duty operations. The motor features a totally enclosed fan cooled design, ball bearings, and a steel frame for durability and reliability. Its high service factor of 1.15 and nominal efficiency of 86.5% make it an ideal choice for applications requiring high performance and low energy consumption. Suitable for use in factories, warehouses, and other industrial settings, this motor is a reliable and efficient solution for demanding operations.
Top product features:
- Three-phase operation for efficient power distribution
- Totally Enclosed Fan Cooled motor enclosure design for reliable operation in harsh environments
- Ball motor bearings for smooth and durable operation
Top product applications:
- Industrial Automation
- Pumping Systems
- Conveyor Systems
General Purpose Motor, Three-Phase, Totally Enclosed Fan Cooled Motor Enclosure Design, 3 HP, Nameplate RPM 3,450, Frame 184TC, Voltage 208-230/460V AC, 60 Hz Hz, Three Phase, Full Load Amps 7.2/3.6 A, C-Face Motor Mounting Type, Motor Thermal Protection None, Ins. Class F, Motor Service Factor 1.15, Ball Motor Bearings, Motor Frame Material Steel, Max. Ambient Temp. 40 Degrees C, CW/CCW Motor Shaft Rotation, Nominal Efficiency 86.5 Percent, Continuous Duty, 3001-3600, CSA, CSA EEV, UR
Additional Information
- Country of Origin: US
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 19.20
- Package Width: 14.00
- Package Height: 13.10
- Package Weight: 53.70
Product info last updated on February 2, 2026 12:16pm UTC
Category: Motors
