Capacitor-Start/Run General Purpose Motor, 1 1/2 hp HP, 115/230V AC Voltage, 145T Frame MPN:EL3514T
Discount: See in Cart
Free Shipping
In Stock
Free Shipping
In Stock
SKU
510-G8375175
Capacitor-Start/Run General Purpose Motor, 1 1/2 hp HP, 115/230V AC Voltage, 145T Frame
This 1.5 hp single-phase motor from BALDOR-RELIANCE is a reliable and efficient solution for a variety of applications, including industrial processes, commercial equipment, and residential appliances. Its capacitor-start/run design provides a high starting torque and smooth operation, making it suitable for demanding tasks. The motor's totally enclosed fan-cooled design ensures reliable performance in harsh environments, while its NEMA Design L rating meets rigorous safety standards. Ideal for use in applications such as pumps, fans, and conveyor systems, this motor offers a high service factor and can operate continuously at temperatures up to 40°C.
Top product features:
- Totally Enclosed Fan Cooled design for improved motor durability and reduced maintenance
- Continuous duty cycle for uninterrupted operation
- 60 Hz operation for compatibility with standard household electrical supplies
Top product applications:
- Pump and irrigation systems
- Conveyor systems
- Power tools and machinery
General Purpose Motor, Single Phase, Motor Design Capacitor-Start/Run, 1 1/2 hp HP, Nameplate RPM 1,800 RPM, No. of Speeds 1, Voltage 115/230V AC, Full Load Amps 6.1 A, 145T Frame, Usable @ 208V Not Usable at 208V, Usable @ 200V Not Usable at 200V, Hz 60 Hz, Motor Service Factor 1.15, Max. Ambient Temp. 40 Degrees C, Motor Thermal Protection None, Duty Cycle Continuous, Ins. Class F, NEMA Design L, Motor Enclosure Design Totally Enclosed Fan Cooled, Motor Shaft Rotation CW/CCW
Additional Information
- Country of Origin: US
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 11 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 15.75
- Package Width: 10.00
- Package Height: 9.25
- Package Weight: 58.00
Product info last updated on February 23, 2026 12:29pm UTC
Category: Motors
