Capacitor-Start/Run General Purpose Motor, 1 hp HP, 115/230V AC Voltage, 56C Frame
The BALDOR-RELIANCE Capacitor-Start/Run General Purpose Motor is a reliable and efficient solution for various applications. Suitable for use in 115/230V AC environments, this motor is ideal for single-phase applications where high torque is required. With a 1 hp output and 3,600 RPM nameplate speed, it is perfect for applications such as pumps, fans, and compressors. The motor's totally enclosed fan-cooled design ensures reliable operation in harsh environments, while its continuous duty cycle and 1.25 service factor make it a versatile choice for a wide range of industries and applications.
Top product features:
- Totally Enclosed Fan Cooled design for improved heat dissipation and motor longevity
- Continuous duty cycle for reliable operation under heavy loads
- 60 Hz operation for compatibility with standard household electrical systems
Top product applications:
- Pumps and water treatment systems
- Fans and blowers for industrial applications
- Conveyor systems and material handling equipment
General Purpose Motor, Single Phase, Motor Design Capacitor-Start/Run, 1 hp HP, Nameplate RPM 3,600 RPM, No. of Speeds 1, Voltage 115/230V AC, Full Load Amps 6.0 A, 56C Frame, Usable @ 208V Not Usable at 208V, Usable @ 200V Not Usable at 200V, Hz 60 Hz, Motor Service Factor 1.25, Max. Ambient Temp. 40 Degrees C, Motor Thermal Protection Auto, Duty Cycle Continuous, Ins. Class F, NEMA Design N, Motor Enclosure Design Totally Enclosed Fan Cooled, Motor Shaft Rotation CW/CCW
Additional Information
- Country of Origin: US
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 19.20
- Package Width: 14.10
- Package Height: 12.40
- Package Weight: 41.70
