Capacitor-Start/Run General Purpose Motor, 5 hp HP, 230V AC Voltage, 213T Frame MPN:L1508T
Discount: See in Cart
Free Shipping
In Stock
Free Shipping
In Stock
SKU
510-G7909596
Capacitor-Start/Run General Purpose Motor, 5 hp HP, 230V AC Voltage, 213T Frame
This BALDOR-RELIANCE Capacitor-Start/Run General Purpose Motor is a reliable and efficient solution for a variety of applications, including industrial and commercial settings. With a 5 hp HP rating and 230V AC voltage, it's suitable for use in areas where a single-phase motor is required. The motor's capacitor-start/run design provides a high starting torque, making it ideal for applications with heavy loads or variable speed requirements. Its rugged construction and open drip-proof enclosure ensure reliable operation in harsh environments. This motor is perfect for use in manufacturing, pumping, and conveying systems, among other applications.
Top product features:
- Capacitor-start/run design provides efficient starting and operation
- Single-phase motor operation allows for simple installation and setup
- Rigid base mounting type provides stable and secure installation
Top product applications:
- Pumps
- Fans
- Conveyors
General Purpose Motor, Single Phase, Motor Design Capacitor-Start/Run, 5 hp HP, Nameplate RPM 1,800 RPM, No. of Speeds 1, Voltage 230V AC, Full Load Amps 27.0 A, 213T Frame, Usable @ 208V Not Usable at 208V, Usable @ 200V Not Usable at 200V, Hz 60 Hz, Motor Service Factor 1.15, Max. Ambient Temp. 40 Degrees C, Motor Thermal Protection None, Duty Cycle Continuous, Ins. Class F, NEMA Design L, Motor Enclosure Design Open Drip Proof, Motor Shaft Rotation CW/CCW, Motor Mounting Type Rigid Base
Additional Information
- Country of Origin: US
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 21.00
- Package Width: 16.00
- Package Height: 14.50
- Package Weight: 108.00
Product info last updated on February 11, 2026 3:54am UTC
Category: Motors
