Pressure Gauge, 0 to 60 psi, 1 1/2 in Dial, 1/8 in NPT, Center Back Location MPN:401008SL01B60#
Pressure Gauge, 0 to 60 psi, 1 1/2 in Dial, 1/8 in NPT, Center Back Location
This 0 to 60 psi pressure gauge is designed for a wide range of applications, including industrial and commercial use. Its 1 1/2 inch dial and 1/8 inch NPT connection provide precise pressure measurement in a compact package. The gauge is built with high-quality materials, including 304 stainless steel and 316L stainless steel, ensuring durability and accuracy. The glycerin-filled case provides stability and resistance to shock and vibration. Suitable for use in environments with high humidity and temperature fluctuations, this gauge is ideal for applications in manufacturing, oil and gas, and chemical processing.
Top product features:
- Liquid-Filled Case provides stability and dampening of pressure fluctuations
- Glycerin liquid is used in the case for its ability to resist freezing and provide a stable pressure reading
- 316L Stainless Steel is used for the socket and sensor materials to provide high corrosion resistance and durability
Top product applications:
- Industrial Process Control
- Hydraulic System Monitoring
- Power Plant Pressure Regulation
Pressure Gauge, Nominal Dial Size 1 1/2 in, Accuracy +/-3-2-3 Percent, Gauge Case Material 304 Stainless Steel, Process Connection Type NPT, Process Connection Gender Male, Lens Material Polycarbonate, Process Connection Size 1/8 in, Process Connection Location Center Back, Case Color Stainless Steel, IP/NEMA Rating IP66, NEMA4X, Primary Pressure Range 0 to 60, Liquid-Filled Case Yes, Gauge Case Liquid Glycerin, Socket Material 316L Stainless Steel, Sensor Material 316L Stainless Steel
Additional Information
- Country of Origin: BR
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 10 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 2.40
- Package Width: 2.40
- Package Height: 2.70
- Package Weight: 0.50
Product info last updated on March 14, 2026 9:33am UTC
Category: Pressure and Vacuum Measuring
