Pressure Switch, Standard, SPDT, 7/16-20" SAE, 500 to 5000 psi Range, 316 Stainless Steel MPN:APAN41H00MHB055000#-NSR
Discount: See in Cart
Free Shipping
In Stock
Free Shipping
In Stock
SKU
510-G4710404
Pressure Switch, Standard, SPDT, 7/16-20" SAE, 500 to 5000 psi Range, 316 Stainless Steel
This high-performance pressure switch from Ashcroft is designed for a wide range of applications, including industrial processes and equipment. With a 500 to 5000 psi range and compatibility with air and liquids, it provides reliable and accurate pressure measurement. The switch features a 316L stainless steel housing and wetted materials, ensuring durability and resistance to corrosion. Its compact design and NEMA 6 rating make it ideal for use in harsh environments. Suitable for applications such as oil and gas, chemical processing, and power generation, this pressure switch offers a reliable and efficient solution for pressure monitoring and control.
Top product features:
- Pressure switch with a 7/16 in SAE process connection
- Switch operates over a range of 500 to 5000 psi
- Contact form is 1NO/1NC for reliable switching
Top product applications:
- Compressed air systems to control air flow and pressure
- Industrial processes that require precise pressure control
- Hydraulic systems to monitor and regulate pressure
Pressure Switch, Range 500 to 5000 psi, Process Connection 7/16 in SAE, Housing Material 316L Stainless Steel, Wetted Materials 316 Stainless Steel, Buna-N, Compatible With Air and Liquids, Electrical Connection Micro DIN Connector, Contact Form 1NO/1NC, Circuit Type Not Applicable, AC Contact Rating 5 A @ 125/250 V, DC Contact Rating 3 A @ 28 V (Inductive), 5 A @ 28 V (Resistive), NEMA Rating 6, IP Rating IP67, Burst Pressure 50,000 psi, Operating Temp. Range -40 Degrees to 210 Degrees F
Additional Information
- Country of Origin: US
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 40 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 5.70
- Package Width: 2.10
- Package Height: 1.80
- Package Weight: 0.50
