Pressure Switch, Standard, SPDT, 7/16-20" SAE, 750 to 7500 psi Range, 316 Stainless Steel MPN:APAN41H00MHB057500#-NSR
Discount: See in Cart
Free Shipping
In Stock
Free Shipping
In Stock
SKU
510-G4706502
Pressure Switch, Standard, SPDT, 7/16-20" SAE, 750 to 7500 psi Range, 316 Stainless Steel
The Ashcroft Pressure Switch is a reliable and versatile solution for a wide range of industrial applications. Suitable for use with air and liquids, this pressure switch is designed to operate in extreme temperatures and pressures, making it ideal for applications in oil and gas, power generation, and chemical processing. With a durable 316L stainless steel housing and wetted materials, this switch is resistant to corrosion and can withstand pressures up to 50,000 psi. Its compact design and micro DIN connector make it easy to integrate into existing systems, providing accurate and reliable pressure monitoring and control.
Top product features:
- Pressure switch with a range of 750 to 7500 psi
- Has a 7/16 in SAE process connection
- Operates in temperatures ranging from -40 to 210 Degrees F
Top product applications:
- Pressure switch for industrial control systems to monitor and regulate pressure levels in high-pressure applications.
- Pressure switch for oil and gas industry to monitor and control pressure levels in wells and pipelines.
- Pressure switch for hydraulic systems to monitor and regulate pressure levels in machinery and equipment.
Pressure Switch, Range 750 to 7500 psi, Process Connection 7/16 in SAE, Housing Material 316L Stainless Steel, Wetted Materials 316 Stainless Steel, Buna-N, Compatible With Air and Liquids, Electrical Connection Micro DIN Connector, Contact Form 1NO/1NC, Circuit Type Not Applicable, AC Contact Rating 5 A @ 125/250 V, DC Contact Rating 3 A @ 28 V (Inductive), 5 A @ 28 V (Resistive), NEMA Rating 6, IP Rating IP67, Burst Pressure 50,000 psi, Operating Temp. Range -40 Degrees to 210 Degrees F
Additional Information
- Country of Origin: US
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 40 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 5.70
- Package Width: 2.00
- Package Height: 1.80
- Package Weight: 0.50
Product info last updated on March 21, 2026 8:11am UTC
Category: Industrial Electrical Controls and Automation
