Transducer, 0 to3000 psi, Output 1 to 5VDC MPN:G17MEK15CD3000#
Transducer, 0 to3000 psi, Output 1 to 5VDC
This high-precision pressure transducer from Ashcroft is designed for demanding applications that require accurate measurements of pressure up to 3000 psi. With a 1-5VDC output and +/-0.50% accuracy, it provides reliable and precise data for a wide range of industries, including oil and gas, chemical processing, and power generation. Its rugged NEMA 4X rating and IP67 rating ensure it can withstand harsh environments, making it ideal for use in extreme temperatures, high humidity, and dirty or corrosive conditions. Suitable for use in a variety of applications, including pressure monitoring, control systems, and data acquisition.
Top product features:
- Measures pressure up to 3000 psi
- Provides a 1-5V DC output signal
- Has a NEMA 4X rating for protection against environmental factors
Top product applications:
- Oil and Gas Industry: The Ashcroft pressure transducer can be used to measure pressure in oil and gas wells, pipelines, and storage tanks.
- Industrial Automation: The transducer can be integrated into industrial automation systems to monitor and control pressure in various processes, such as chemical processing, power generation, and water treatment.
- Research and Development: The high accuracy and wide pressure range of the Ashcroft transducer make it suitable for research and development applications, such as testing and validation of new equipment and processes.
Pressure Transmitter, Minimum Pressure 0 psi, Maximum Pressure 3,000 psi, Electrical Connections DIN 43650 Form A Connector, Output 1 to 5V DC, Accuracy +/-0.50 Percent Full Scale, Number of Wires 3, Process Connection Gender Male, Process Connection Size 7/16 in, Process Connection Type SAE, Power Required 9 to 36V DC, NEMA Rating NEMA 4X, IP Rating IP67, Series G2, Wiring Entry 1/2 in FNPT Conduit Connection, Maximum Operating Temperature 257 Degrees F
Additional Information
- Country of Origin: US
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 12 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 3.20
- Package Width: 1.40
- Package Height: 6.10
- Package Weight: 0.20
Product info last updated on February 1, 2026 8:47am UTC
Category: Pressure and Vacuum Measuring
