Transducer, 0 to 60 psi, Output 1 to 5VDC MPN:G17MEK15CD60#
Transducer, 0 to 60 psi, Output 1 to 5VDC
This high-accuracy pressure transducer from Ashcroft offers precise measurements in a wide range of applications, from industrial processes to research and development. With a measurement range of 0 to 60 psi and an output of 1 to 5VDC, it provides reliable data for monitoring and control systems. Its compact design and durable construction make it suitable for use in harsh environments, including high temperatures and corrosive substances. The transducer is ideal for applications such as pressure measurement in hydraulic systems, pneumatic systems, and gas monitoring, as well as research and development in fields like aerospace and automotive engineering.
Top product features:
- Measures pressure up to 60 psi
- Provides a 1 to 5V DC output
- Maintains accuracy within +/-0.50 Percent Full Scale
Top product applications:
- Oil and Gas Industry: The Ashcroft transducer is suitable for use in oil and gas applications where high pressure and temperature conditions are present.
- Chemical Processing: The transducer's NEMA 4X rating and IP67 rating make it suitable for use in chemical processing environments where exposure to chemicals and moisture is a concern.
- Water Treatment Plants: The transducer's ability to operate in a wide temperature range (-40 to 257°F) makes it suitable for use in water treatment plants where temperatures may fluctuate significantly.
Pressure Transmitter, Minimum Pressure 0 psi, Maximum Pressure 60 psi, Electrical Connections DIN 43650 Form A Connector, Output 1 to 5V DC, Accuracy +/-0.50 Percent Full Scale, Number of Wires 3, Process Connection Gender Male, Process Connection Size 7/16 in, Process Connection Type SAE, Power Required 9 to 36V DC, NEMA Rating NEMA 4X, IP Rating IP67, Series G2, Wiring Entry 1/2 in FNPT Conduit Connection, Maximum Operating Temperature 257 Degrees F, Minimum Operating Temperature -40 Degrees F
Additional Information
- Country of Origin: US
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 12 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 3.30
- Package Width: 1.50
- Package Height: 6.10
- Package Weight: 0.25
Product info last updated on February 23, 2026 2:14pm UTC
Category: Pressure and Vacuum Measuring
